4-Stroke Diesel Engine Test Rig

Overview

The 4-Stroke Diesel Engine Test Rig is a comprehensive IC engine laboratory equipment designed for engineering colleges, polytechnics, and research institutions. It enables students to study the performance, combustion, and efficiency characteristics of a diesel engine under different load conditions.

This test rig provides practical exposure to engine operation, fuel consumption analysis, and emission behavior, making it an essential system for thermal engineering and mechanical labs.

Product Range

★ Single-cylinder 4-stroke diesel engine test rigs
★ Water-cooled and air-cooled variants available
★ Eddy current / hydraulic / rope brake dynamometer options
★ Manual and computerized data acquisition systems

Key Features

★ Robust diesel engine with variable load control
★ Accurate fuel consumption and airflow measurement
★ Digital speed, temperature, and pressure indicators
★ Dynamometer for load application and performance testing
★ Safety guards, emergency stop, and stable base frame

Applications

★ Performance testing of 4-stroke diesel engines
★ Brake power, indicated power, and efficiency calculations
★ Study of combustion and heat balance
★ Academic experiments in thermal and IC engine labs
★ Suitable for engineering colleges and skill training centers

Learning Outcomes

★ Understanding 4-stroke diesel engine working principle
★ Calculation of mechanical, thermal, and volumetric efficiency
★ Hands-on experience with engine testing procedures
★ Analysis of engine performance under varying loads
